500 kVA K-13 Cast Resin Dry-Type Harmonic Transformer

By /
500 kVA K-13 Cast Resin Dry-Type Harmonic Transformer
Dry Type Transformer - Epoxy Resin Cast Transformer
Dry Type Transformer - Epoxy Resin Cast Transformer

500 kVA K-13 Cast Resin Dry-Type Harmonic Transformer

This 500 kVA K-13 cast resin dry-type harmonic transformer is purpose-built for facilities with high non-linear loads. It comes with a 200% rated neutral conductor, Class F insulation system, and flexible primary voltage options of 11 kV / 22 kV / 33 kV, delivering 415 V / 240 V secondary output. Fully compliant with IEEE C57.110, AS/NZS 60076 and IEC 60076-11, it is suitable for commercial buildings, data rooms and mid-sized industrial plants.

Category:

Applications

  • Commercial office towers, server rooms, and medical hospital imaging suites.

Features

  • Compact footprint suitable for indoor electrical substations and commercial building vaults.
  • 200% neutral sizing eliminates harmonic neutral overheating risks.

Dry Type Transformer - Epoxy Resin Cast Transformer

Technical Specifications
Rated Capacity500 kVA
K-Factor RatingK-13
Primary Voltage11 kV / 22 kV / 33 kV
Secondary Voltage415V / 240V
Neutral Rating200% Capacity
InsulationClass F (155°C)
StandardIEEE C57.110 / AS/NZS 60076 / IEC 60076-11
